Uvod
The ASUS ROG Strix Helios II is an EATX mid-tower gaming PC case designed for high-performance builds. It features dual tempered glass panels, an aluminum diamond-grille front panel, and advanced cooling capabilities with four pre-installed fans. This manual provides essential information for setting up, operating, maintaining, and troubleshooting your PC case.
Nastavitev
Razpakiranje in prvi pregled
Carefully remove the PC case from its packaging. Inspect the case for any signs of damage during transit. Ensure all accessories listed in the packing list are present.
Tool-Free Side Panel Access
The ROG Strix Helios II features tool-less side panels for easy access to internal components. Simply unlatch the panels to open the case. This design simplifies installation and maintenance.
Figure 1: Easy Installation & Maintenance features, including tool-free side panel and detachable PSU bracket.
Namestitev matične plošče
The case supports E-ATX (up to 12" x 10.9"), ATX, Micro-ATX, and Mini-ITX motherboards. Install your motherboard onto the standoffs provided. Ensure all screws are securely fastened.
Namestitev napajalnika
The case includes a rear detachable PSU bracket. Install your power supply (up to 220mm in length) into the bracket, then secure the bracket to the case. This design simplifies PSU installation and cable routing.
Namestitev grafične kartice
The case supports graphics cards up to 450mm long. It features a patented graphics card slot clamp for secure horizontal installation. Vertical GPU mounting is also supported.
Figure 2: Graphics card installation options, including horizontal and vertical mounting.
Upravljanje kablov
Utilize the multifunction cover with graphics card holders, PSU shroud, cable cover, and rear cable clips for effortless cable management. This ensures a tidy build and optimized airflow.
Figure 3: Dedicated features for organized cable routing.
Operating the PC Case
Advanced I/O Panel
The top I/O panel provides convenient access to connectivity and controls. It features two USB 20Gbps Type-C ports, four USB-A 3.0 ports, an ARGB-lighting control button, and a fan-speed PWM control button.
Nadzor osvetlitve ARGB
Use the dedicated ARGB-lighting control button on the I/O panel to cycle through various lighting effects and colors for compatible components.
Nadzor hitrosti ventilatorja
Adjust the fan speeds using the PWM control button on the I/O panel to balance cooling performance and noise levels.
Cooling and Thermal Performance
The ROG Strix Helios II is engineered for optimal thermal performance. It comes with four pre-installed 140 x 28mm performance fans that deliver high airflow while maintaining low noise levels.
Figure 4: Airflow and noise level specifications for optimal thermal performance.
Fan and Radiator Capacity
The case supports up to 420mm radiators and 7 x 120mm fans, providing extensive cooling options for high-end components.
Figure 5: Detailed fan and radiator compatibility.
Vzdrževanje
Čiščenje filtra za prah
The case features a 3D-structured filter on the front panel and removable dust covers to prevent dust buildup. Regularly clean these filters to maintain optimal airflow and component longevity. To clean, gently remove the filters and use compressed air or a soft brush to clear accumulated dust. Reinstall once clean and dry.
Odpravljanje težav
Splošna vprašanja
If you encounter issues such as unexpected shutdowns, overheating, or component recognition problems, first ensure all power and data cables are securely connected. Verify that all fans are spinning correctly and dust filters are clean. Consult your component manuals for specific troubleshooting steps.
Obrnite se na podporo
For persistent issues, please refer to the ASUS support webspletno mesto ali se za dodatno pomoč obrnite na njihovo službo za stranke.
Specifikacije
| Funkcija | Podrobnost |
|---|---|
| Znamka | ASUS |
| Ime modela | ROG STRIX HELIOS II GX601S BLACK |
| Vrsta ohišja | Srednji stolp |
| Združljivost matične plošče | E-ATX (up to 12" x 10.9"), ATX, Micro-ATX, Mini-ITX |
| Material | Aluminij, kaljeno steklo |
| Teža predmeta | 39.7 funtov |
| Dimenzije izdelka (DxŠxV) | 22.2 x 9.8 x 23.3 palcev |
| Največja dolžina GPE | 450 mm |
| Največja višina hladilnika procesorja | 190 mm |
| Največja dolžina PSU | 220 mm |
| Vnaprej nameščeni ventilatorji | 4 x 140 x 28mm performance fans |
| Podpora za radiatorje | Do 420 mm |
| V/I vrata | 2x USB 20Gbps Type-C, 4x USB-A 3.0, ARGB-lighting control, Fan-speed PWM control |
Garancija in podpora
Informacije o garanciji
Please refer to the official ASUS website or your product's warranty card for detailed warranty terms and conditions. Keep your proof of purchase for warranty claims.
Podpora uporabnikom
For technical assistance, product inquiries, or service requests, visit the ASUS support website or contact their customer service. Support contact information can typically be found on the ASUS official webmestu ali v embalaži izdelka.
Dodatne funkcije
Ergonomic Case Straps
The ROG Strix Helios II features ergonomic and stylish X-shaped woven straps, designed to comfortably carry your prized build. These straps support up to 50kg.
Figure 6: Case straps for convenient transport.
Premium Design & Aesthetics
The case boasts a premium design with an aluminum front panel featuring a diamond-grille design and a 3D-structured filter, enhancing both aesthetics and cooling efficiency.
Figure 7: Front panel design details.
Uradni videoposnetki izdelkov
Video 1: Uradni konecview of the ASUS ROG Strix Helios II computer case, showcasinnjegove lastnosti in obliko.
