Uvod
This manual provides comprehensive instructions for the safe installation, operation, and maintenance of your Progress Lighting P8222-28-30K LED Flush Mount fixture. Please read all instructions carefully before beginning installation and retain this manual for future reference.
Varnostne informacije
OPOZORILO: Risk of electric shock. Disconnect power at the fuse box or circuit breaker before installation or servicing. Consult a qualified electrician if you are unsure about the installation process. All wiring connections must be in accordance with local codes and ordinances.
POZOR: Suitable for wet locations. Minimum 90°C supply conductors. Replace LED assembly with Progress Lighting Part No. 93072947-3030 & 93072948-2000.
Vsebina paketa
Verify that all parts are included before beginning installation.
- A: Napeljava (količina: 1)
Image: Diagram illustrating the main fixture component (A) and its internal wiring, along with the mounting strap and wire nuts.
Vsebina strojne opreme (ni dejanska velikost)
- AA: Mounting strap (Quantity: 1)
- BB: Žična matica (količina: 2)
Image: Close-up of the mounting strap, two wire nuts, and two mounting screws, essential hardware for installation.
Seznam združljivosti zatemnilnikov
This fixture is dimmable when used with compatible wall dimmers. The following dimmers are compatible:
- Leviton - 6672
- Leviton - 6674
- Lutron - AYCL-153P
- Lutron - TGCL-153P
- Lutron - AY-600
Image: Visual representation highlighting the integrated LED design (no bulbs required) and a hand operating a compatible wall dimmer switch, indicating dimmable functionality.
Namestitev (Nastavitev)
The LED Surface Mount Series offers maximum versatility for both recessed and flush mount applications. Choose the option below that suits your installation needs.
Podometna namestitev
For flush mount applications, the fixture installs directly into a standard J-box. Simply install the snap-in adapter into the J-box, then snap the fixture into place using the flush mount clip. The quick-link wiring system completes the flush mount installation.
Vgradna namestitev
For recessed applications, the P8222 and P8007 models include an adjustable mounting option that fits 6", 5" or 4" recessed housings. Simply twist-and-push into the recessed housing and finish with the quick-link wiring. The P8222 also includes an E26 Edison Base adapter for a retrofit snap-in option.
Image: Detailed diagrams showing both flush mount installation with a snap-in adapter and recessed installation with a twist-and-push mechanism, including wiring steps.
Video: An official Progress Lighting video discussing close-to-ceiling lighting trends and applications, demonstrating various fixture types and their suitability for different rooms.
Navodila za uporabo
Once installed, the LED Flush Mount operates via a standard wall switch. For dimming functionality, ensure a compatible dimmer switch is installed (refer to the Dimmer Compatibility List). The integrated LED light source provides 3000K white light with 1170 lumens output and is designed for flicker-free dimming down to 10% brightness.
Vzdrževanje
To clean the fixture, ensure power is disconnected. Wipe with a soft, dry cloth. Do not use abrasive cleaners or solvents as they may damage the finish or electrical components. The integrated LED is designed for long-term use and does not require bulb replacement.
Odpravljanje težav
| Težava | Možen vzrok | rešitev |
|---|---|---|
| Lučka se ne prižge | No power to fixture; Loose wiring; Faulty switch. | Check circuit breaker/fuse. Ensure all wire connections are secure. Test or replace switch. |
| Luč nepravilno utripa ali se zatemni | Nezdružljivo zatemnilno stikalo; ohlapna ožičenje. | Verify dimmer compatibility (see list). Check wiring connections. |
| Light output is low | Dimmer setting too low; Integrated LED issue. | Adjust dimmer to maximum. If problem persists, contact customer service. |
Specifikacije
Slika: Spodnja stran view of the fixture, displaying electrical ratings, model number (P8222-28-30K), and certifications.
Image: Diagram showing the dimensions of the fixture: 7.25 inches in width and 1.1875 inches in height.
| Funkcija | Podrobnost |
|---|---|
| Ime modela | P8222-28-30K |
| Znamka | Razsvetljava Progress |
| barva | Bela |
| Material | Legirano jeklo, steklo (senčnik) |
| Slog | Sodobna |
| Oblika svetilke | Blizu stropa |
| Dimenzije izdelka | 7.25 cm D x 7.25 cm Š x 1.19 cm V |
| Notranja/zunanja uporaba | Notranja |
| Vir napajanja | AC |
| Vrsta namestitve | Flush Mount, Recessed (with adapter) |
| Posebna funkcija | Možnost zatemnitve |
| Vrsta svetlobnega vira | Integrirana LED |
| Število svetlobnih virov | 1 |
| Svetla barva | 3000K bele barve |
| Svetlost | 1170 lumnov |
| Učinkovitost | 67.57 lumnov na vat |
| Stopnja vodoodpornosti | Vodoodporen |
| Zahtevana montaža | ja |
| Teža predmeta | 1 funta |
| UPC | 785247205615 |
Garancija
Ta svetilka Progress Lighting je prekrita z 5-letna omejena garancija. This warranty guarantees your complete satisfaction with your purchase and covers defects in materials and workmanship under normal use. For warranty claims or further details, please contact customer service.
Podpora
If you have any questions, are missing parts, or require assistance, please contact Progress Lighting Customer Service:
- telefon: 1-800-447-0573
- E-pošta: customerservice@progresslighting.com
- ure: 8–8 (vzhodnoameriški čas), od ponedeljka do petka
