1. Uvod
Thank you for choosing the Jauarta OCS-P2 Electronic Crane Scale. This high-precision weighing device is designed for various industrial applications, including factories, warehouses, docks, and grain industries. Its portable design ensures convenience and ease of use. Please read this manual thoroughly before operation to ensure safe and correct usage.
Ključne značilnosti:
- Visoka natančnost: Equipped with a high-precision weighing sensor, this electronic hanging scale undergoes rigorous high and low-temperature testing to ensure accurate measurements.
- Visoka zmogljivost: Featuring a thickened hook and lifting ring, this electronic hanging scale offers a high load capacity of up to 1500 kg.
- Brezžični daljinski upravljalnik: The scale includes a wireless remote control, allowing operation from up to 20 meters away for enhanced convenience.
- Jasen LED zaslon: A large LED display provides clear and quick readings. Multiple measurement units are supported to meet diverse requirements (kg, lb, N, jin, viss).
- Vzdržljiva konstrukcija: Ima aluminijasto zlitino casing, alloy steel sensor, and fine steel lifting ring and hook. The display panel is made of high-temperature resistant acrylic plate.
2. Varnostne informacije
Always follow basic safety precautions when using this product to reduce the risk of injury or damage. This scale is designed for weighing; do not use it for lifting or transporting people.
- Ensure the scale is securely attached to a suitable lifting mechanism before use.
- Ne prekoračite največje nosilnosti 1500 kg.
- Roke in telo držite stran od visečih bremen.
- Do not operate the scale in extreme weather conditions or environments with excessive dust or moisture unless specifically designed for such conditions.
- Baterije takoj zamenjajte, ko se prikaže indikator nizkega stanja baterije.
3. Sestavni deli izdelka
The Jauarta OCS-P2 Electronic Crane Scale package includes the following items:
- Electronic Crane Scale Unit (with LED display, lifting ring, and hook)
- Brezžični daljinski upravljalnik
- Uporabniški priročnik (ta dokument)
Opomba: 4 AA batteries for the scale and 2 AAA batteries for the remote control are ni vključeno in ga je treba kupiti posebej.
Slika 3.1: Spredaj view of the Jauarta OCS-P2 Electronic Crane Scale, showing the LED display, lifting ring, and hook.
Slika 3.2: Zadaj view of the Jauarta OCS-P2 Electronic Crane Scale, showing the battery compartment.
4. Nastavitev
4.1 Namestitev baterije
- For the Scale: Locate the battery compartment on the back of the crane scale. Open the cover and insert 4 AA batteries, ensuring correct polarity (+/-). Close the battery cover securely.
- Za daljinski upravljalnik: Locate the battery compartment on the back of the remote control. Open the cover and insert 2 AAA batteries, ensuring correct polarity (+/-). Close the battery cover securely.
4.2 Attaching the Scale
- Ensure the lifting ring is securely fastened to the top of the scale unit.
- Attach the crane scale to your lifting equipment (e.g., hoist, crane) using the lifting ring. Ensure the connection is stable and capable of supporting the maximum load.
- Verify that the bottom hook is securely attached to the scale unit.
5. Navodila za uporabo
5.1 Vklop/izklop
- Za vklop: Pritisnite VKLOP/IZKLOP button on the scale or the remote control. The LED display will light up and show '0.0' when ready.
- Za izklop: Pritisnite in držite VKLOP/IZKLOP button for a few seconds until the display turns off.
5.2 Tehtanje
- Ensure the scale is powered on and displays '0.0'.
- Carefully attach the item to be weighed to the scale's hook.
- The weight will be displayed on the LED screen. Wait for the reading to stabilize.
5.3 Funkcija tare
Funkcija Tara vam omogoča odštevanje teže posode ali embalaže, tako da se izmeri le neto teža artikla.
- Place the empty container or packaging on the hook.
- Pritisnite TARA/NIČ button on the scale or remote control. The display will reset to '0.0'.
- Place the item to be weighed inside the container. The display will show the net weight of the item.
5.4 Pretvorba enot
The scale supports multiple measurement units: kg (kilograms), lb (pounds), N (Newtons), jin, and viss.
- Pritisnite ENOTA button on the scale or remote control to cycle through the available units. The current unit will be indicated on the LED display.
5.5 Funkcija zadrževanja
The Hold function allows you to freeze the displayed weight reading.
- Med tehtanjem predmeta pritisnite PRIDRŽI button on the scale or remote control. The displayed weight will be held, indicated by a 'HOLD' symbol on the screen.
- Pritisnite PRIDRŽI ponovno pritisnite gumb, da sprostite odčitek in se vrnete na tehtanje v realnem času.
5.6 Delovanje daljinskega upravljalnika
The wireless remote control allows for convenient operation from a distance of up to 20 meters.
Figure 5.1: Jauarta OCS-P2 Electronic Crane Scale shown with its wireless remote control.
Figure 5.2: Close-up of a hand operating the remote control, showing various function buttons.
The remote control duplicates the main functions of the scale, including Power On/Off, Tare/Zero, Unit conversion, and Hold. Ensure the remote has fresh AAA batteries for optimal performance.
6. Vzdrževanje
6.1 Čiščenje
- Obrišite tehtnico z mehko damp krpo. Ne uporabljajte abrazivnih čistil ali topil.
- Ensure no liquid enters the display or battery compartments.
6.2 Zamenjava baterije
- When the low battery indicator appears on the LED display, replace the batteries promptly to ensure accurate readings and prevent damage from battery leakage.
- Always replace all batteries at once with new ones of the same type.
6.3 Shranjevanje
- Tehtnico shranjujte na suhem in hladnem mestu, stran od neposredne sončne svetlobe in ekstremnih temperatur.
- If storing for an extended period, remove all batteries from both the scale and the remote control to prevent leakage.
7. Odpravljanje težav
| Težava | Možen vzrok | rešitev |
|---|---|---|
| Tehtnica se ne vklopi | Prazne ali nepravilno vstavljene baterije. | Baterije zamenjajte z novimi in pri tem pazite na pravilno polarnost. |
| Netočni odčitki | Overload; unstable environment; scale not zeroed; damaged sensor. | Ensure load is within capacity. Use in a stable environment. Press TARE/ZERO before weighing. Contact support if sensor damage is suspected. |
| Display shows 'OL' or 'Err' | Preobremenitev. | Remove the load immediately. Ensure the weight does not exceed 1500 kg. |
| Daljinski upravljalnik ne deluje | Dead batteries; out of range; obstruction. | Replace AAA batteries. Ensure remote is within 20 meters of the scale. Remove any obstructions between remote and scale. |
8. Specifikacije
- Model: OCS-P2
- barva: Modra
- Material izdelka: Aluminijeva zlitina casing
- Material senzorja: Legirano jeklo
- Lifting Ring & Hook Material: Fino jeklo
- Način prikaza: LED zaslon
- Display Panel Material: High-temperature resistant acrylic plate, cast iron spray front plate
- Power Source (Scale): 4 x AA baterije (niso vključene)
- Power Source (Remote Control): 2 x AAA baterije (niso priložene)
- Wireless Remote Control Distance: ≤ 20 meters / 65.6 feet
- Maximum Weighing Capacity: Približno 1500 kg
- Merske enote: kg, lb, N, jin, viss
- Mere izdelka (D x Š x V): 28 x 18 x 10 cm
- Teža izdelka: 1.6 kg
- Proizvajalec: Jauarta
- Država izvora: Kitajska
Figure 8.1: Dimensions of the Jauarta OCS-P2 Electronic Crane Scale.
9. Garancija in podpora
Warranty information for the Jauarta OCS-P2 Electronic Crane Scale is not provided in the product data. For any support inquiries, technical assistance, or questions regarding spare parts, please contact your retailer or the manufacturer directly.
Razpoložljivost rezervnih delov: Informacije niso na voljo.
