HOMVILLA Digital Alarm Clock with Large LED Temperature Display

Uvod

Thank you for choosing the HOMVILLA Digital Alarm Clock. This manual provides comprehensive instructions for the proper setup, operation, and maintenance of your new device. Please read this guide thoroughly before use to ensure optimal performance and longevity of your alarm clock.

Lastnosti izdelka

• Velik LED zaslon: 5.6-inch mirror LED screen for clear time and temperature viewing.
• Dual Alarm with Snooze: Set two independent alarms with adjustable snooze duration.
• Nastavljiva svetlost: Four levels of brightness, with automatic dimming between 10 PM and 6 AM.
• USB Powered with Battery Backup: Includes a USB charging cable for power; built-in button battery saves settings during power outages.
• Inteligentno glasovno upravljanje: Display activates for 5 seconds with ambient noise above 90 decibels or a tap.
• Funkcija pomnilnika: Retains settings when powered off, provided the internal battery is sufficiently charged.
• 12/24-urni format: Supports both time display formats.
• Elegant Mirror Design: Compact and stylish, can also function as a mirror.

Nastavitev

1. Napajalni priključek

Connect the provided USB cable to the alarm clock's 5V/1A power input port (located on the back). Plug the other end into a compatible USB power adapter (not included) or a USB port. The LED display will light up.

Slika: Nazaj view of the HOMVILLA Digital Alarm Clock, highlighting the USB power input and various control buttons.

2. Varnostno kopiranje baterije

The alarm clock has a built-in button battery. This battery ensures that your time and alarm settings are saved in case of a power interruption. The clock requires continuous USB power for the display to remain constantly lit. If operating on battery backup only, the display will turn off to conserve power and will activate for 5 seconds when a sound or touch is detected.

Image: The alarm clock demonstrating its memory function, showing that settings are retained even when the main power is off.

Navodila za uporabo

1. Time Setting (12/24 Hour Format)

1. Press and hold the "TIME SET" button (often labeled with a clock icon) on the back of the unit. The hour digits will begin to flash.
2. Za nastavitev ure uporabite gumba "GOR" ali "DOL".
3. Press "TIME SET" again to move to minute adjustment. Use "UP" or "DOWN" to set the minutes.
4. Press "TIME SET" a third time to select between 12-hour (with AM/PM indicator) or 24-hour format. Use "UP" or "DOWN" to toggle.
5. Press "TIME SET" one last time to confirm and exit time setting mode.

2. Alarm Setting (Dual Alarm & Snooze)

This clock supports two independent alarms (Alarm 1 and Alarm 2).

1. Nastavitev alarma 1:
   • Slide the "ALARM1 ON/OFF" switch to "ON". The alarm icon will appear on the display.
   • Press and hold the "ALARM SET" button (often labeled with a bell icon). The hour digits for Alarm 1 will flash.
   • Use "UP" or "DOWN" to adjust the alarm hour.
   • Press "ALARM SET" again to move to minute adjustment. Use "UP" or "DOWN" to set the alarm minutes.
   • Press "ALARM SET" to confirm.
2. Nastavitev alarma 2: Follow the same steps as Alarm 1, using the "ALARM2 ON/OFF" switch.
3. Funkcija dremeža: When an alarm sounds, press the "SNOOZE/LIGHT" button on top of the clock. The alarm will pause and sound again after 5 minutes. The alarm icon will flash during snooze mode. To turn off the alarm completely, press any other button on the back of the clock.

Image: Illustration of the snooze function and the ability to set two distinct alarms for different schedules.

3. Nastavitev svetlosti

The display has 4 adjustable brightness levels. Press the "SNOOZE/LIGHT" button (on top) to cycle through the brightness levels (1-4). The clock also features an automatic dimming function, reducing brightness between 10:00 PM and 6:00 AM to avoid disturbance during sleep.

Image: Four distinct brightness levels of the alarm clock display, demonstrating the adjustable illumination.

4. Intelligent Voice Control Function

When the clock is powered by its internal battery (not connected via USB), the display will turn off to save power. It will activate for 5 seconds if the ambient noise reaches 90 decibels or if the desktop where it's placed is lightly knocked. When connected via USB, the display remains continuously lit, and the voice control function is inactive.

Image: The alarm clock activating its display in response to sound, illustrating the intelligent voice control feature.

5. Prilagoditev glasnosti

The alarm volume can be adjusted. While in alarm setting mode or when an alarm is sounding, use the "VOLUME ADJUSTMENT" buttons (often labeled with speaker icons) on the back to increase or decrease the volume.

Image: Diagram showing the location and function of the volume adjustment controls on the alarm clock.

Vzdrževanje

• Clean the clock's surface with a soft, dry cloth. Avoid using abrasive cleaners or solvents.
• Keep the device away from direct sunlight, high temperatures, and high humidity.
• Do not disassemble the unit. Refer to qualified personnel for any repairs.

Odpravljanje težav

Specifikacije

• Znamka: HOMVILLA
• Številka modela: Moderno
• barva: Rose
• Vrsta zaslona: Digitalna LED
• Dimenzije izdelka: 14.5 cm (L) x 6.5 cm (H) x 3.2 cm (W) / 5.7 x 2.56 x 1.26 inches
• Velikost zaslona: 5.6 palcev
• vir energije: Electric Cable (USB 5V/1A)
• Baterija: 1 C battery (included, for backup)
• Material: Akrilonitril butadien stiren (ABS) plastika
• Teža artikla: 220 gramov
• Posebne lastnosti: Alarm, Temperature Display, Snooze, Adjustable Brightness, Voice Control, Memory Function
• Tehnologija povezljivosti: USB
• Vrsta gibanja: Kvarc

Garancija in podpora

HOMVILLA offers a lifetime warranty for this product. For any questions, technical support, or warranty claims, please contact HOMVILLA customer service through your purchase platform or the official HOMVILLA webmesto.
